FD30 3 Ton Warehouse Lifting Equipment Forklift Truck 12 Months Warranty Time

Product Details:
Place of Origin: China (Mainland)
Brand Name: HIFOUNE
Certification: ISO9001:2008/CE
Model Number: FD30
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Price: Negotiable
Packaging Details: Export Packaging
Delivery Time: 7-30 Days
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 250 Units per Month

Detail Information

Power Source: Diesel Engine Condition: New
Tyre Number: 2/2 Tyre Type: Pneumatic Tyre
Loading Capacity: 3 Ton Warranty Time: 12 Months
Overall Dimensions: 2750X1240X2130mm Fork Size: 1220X125X45mm
High Light:

warehouse material handling equipment

,

warehouse heavy equipment

Product Description

Diesel Engine Forklift Truck FD30 Hydraulic Four Wheel 3Ton



1. Advantages / Features



  • Equipped with powerful and reliable engines with excellent environmental performace.

  • XINCHAI,MITSUBISH and japanese ISUZU engines are optional.

  • The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle; -- Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.

  • Double-axle 4 wheel drive,improved safety and stability of the machine.And articulated body design reduce the turning radius.The driver can get a more comfortable drive environments and more relax.

  • All car LED lights, high brightness, long life, energy saving and environmental protection.



2. Technical Parameters



MAIN TECHNICAL PARAMETERS



Model UNIT FD30T
Specifications Power Unit   Diesel
Operator Type   Driver/seat
Transmission Box Type   Electronic hydraulic transmisson
Rated Capacity kg 3000
Load Center mm 500
Max.Lifting Height mm 3000
Tyre Type   Pneumatic Tyre
Tyre Number (Front/Rear)   2/2
Tyre Size (Front/Rear)   28×9-15-14PR/6.5-10-10PR
Performance

Lifting Speed

(Loaded/Unloaded)

mm/s 500/550

Lowering Speed

(Loaded/Unloaded)

mm/s 480/450

Travelling Speed

(Loaded/Unloaded)

km/h 19/20

Max.Gradeability

(Loaded)

% 21

Max.Drawbar Pull

(Loaded)

n 18

Mast Tilting Angle

(Fwd/Bwd)

deg 6/12
Free Lifting Height mm 150
Turning Radius mm 2400
Dimensions Overall length (without fork) mm 2705
Overall Width mm 1240
Overhead Guard Height mm 2130
Fork Size (LxWxT) mm 1220×125×45
Mast Height (Fork lowered) mm 2140
Battery (Voltage/Capacity) V/Ah 12/90
Truck Weight kg 4380
Fuel Tank Capacity L 70
Engine Brand   XINCHAI MITSUBISH ISUZU
Model   C490 S4S C240
Rated Power kw/rpm 40/2650 35.3/2250 35.4/2500
Rated torque n-m/rpm 160/1600-2000 169/1700 137.7/1800
Number of cylinder   4 4 4
Displacement   2.67 2.49 2.37





3. Application



Our high quality forklift is widely used in the port,wharf,industrial and mining enterprised,station,warehouse and others.It's suitable to operate on soft soils ,grass, normal terrain ,mud and many other rugged surfaces.



4. Our Advantages



  • World-class quality

  • Factory sale directly with reasonable price

  • Flexible payment terms including T/T,L/C and so on

  • Fast delivery within 30 days after contract established

  • Professional sales team,quality inspection and report, maritime logistics guidance

  • After-sale services:video technical support,24h online support
